Description
MC4 connectors and solar power cable not included.
Buy separately through our site .
Note : If mounting your panels on a roof – Please email us your roof type and
style in order for us to send you a price on your solar panel roof mounting system . If not sure , photograph it and email it to us for identification .
Please note : NB !! – Do not attempt to crimp MC4 solar power connectors without a proper crimp tool – It can and has has caused conductivity problems – we sell a well priced quality MC4 crimp tool under our “cables and connectors ” section in our store.
-
Key Features
- Positive power tolerance.
- Highly reliable low-iron tempered glass.
- Weather proof.
- Wind speed – 2400Pa.
- Snow load – 5400Pa.
- IP 67 junction box.
- PID resistant.
Quality & Safety
- IEC 61215, IEC 61730, IEC 61701 compliant.
- UL 1703 compliant.
- ISO: 9001-2008 Certified Manufacturing Facility.
Warranty
- Limited Power Output Warranty – 25 Years.
- Product Warranty – 10 Years.
Electrical Characteristics
- Peak Power, Pmax (Wp) – 340W.
- Open circuit voltage, Voc (V) – 46.30V.
- Short Circuit current, lsc (A) – 9.54V.
- Voltage at Maximum power, Vmp (V) – 38.14V
- Current at Maximum power, Imp (A) – 8.92A.
- Module Efficiency (%) – 17.59%.
Mechanical Parameters
- Module dimension – 1958mm x 987mm x 40mm.
- Weight: 21.5 Kg.
- No. of Cells – 72.
- Solar cell Type – Poly crystalline cells.
- Front Cover – 3.2mm Thick Low iron tempered glass.
- Frame Material – Silver Anodized Aluminium Alloy.
- Junction Box – 4 Rail IP67.
- PV Connectors: MC4 Compatible
- Cable: 4mm2
