Description
KEY FEATURES
1.Passive Detection
Passively receives only, does not emit any electromagnetic signals, no impact on the surrounding environment
2.Precise Identification
Precisely identify the SN, model, geo-location, speed, altitude, trajectory, and remote controller information of the drones in real time
3.Trajectory Tracking
Multi-target trajectory tracking, pilot (remote control) tracking
4.Position Navigation
Detect the pilot’s (remote controller) position in real-time, one-click to track the pilot and the drone
5.Black and White List
One-click to mark the black and white list, there will be no alarm for white-listed drones
6.Network Management
Support network access to the control platform, to achieve multi-device collaboration, to achieve a wide range of prevention and control scenarios
7.Wireless Intercom
Multi-device wireless network, instant communication, collaborative operations, to support the completion
of command and planning work
8.Graphic Steam
DIY graphic transmission traversing machine detection and identification, record the real-time graphic transmission screen of the drones;
9.Compact and Portable
Light in weight and small in size; Portable, shockproof and drop-proof
Passively receives only, does not emit any electromagnetic signals, no impact on the surrounding environment
2.Precise Identification
Precisely identify the SN, model, geo-location, speed, altitude, trajectory, and remote controller information of the drones in real time
3.Trajectory Tracking
Multi-target trajectory tracking, pilot (remote control) tracking
4.Position Navigation
Detect the pilot’s (remote controller) position in real-time, one-click to track the pilot and the drone
5.Black and White List
One-click to mark the black and white list, there will be no alarm for white-listed drones
6.Network Management
Support network access to the control platform, to achieve multi-device collaboration, to achieve a wide range of prevention and control scenarios
7.Wireless Intercom
Multi-device wireless network, instant communication, collaborative operations, to support the completion
of command and planning work
8.Graphic Steam
DIY graphic transmission traversing machine detection and identification, record the real-time graphic transmission screen of the drones;
9.Compact and Portable
Light in weight and small in size; Portable, shockproof and drop-proof
|
Working Principle
|
Passive detection, does not emit any electromagnetic signals
|
|
Detection Bands
|
900MHz, 1.2GHz, 2.4GHz, 5.8GHz, WiFi；
|
|
Sensitivity
|
-95dBm
|
|
Detection Distance
|
0~3km+ (Different exist due to different environments and drone type)
|
|
Response Time
|
≤5s
|
|
Detection Quantity
|
≥12 Drones (Simultaneous)
|
|
Number of Drone Trajectories
|
≥11 Drones (Simultaneous)
|
|
Position Accuracy
|
≤3m (Available for the drones can be decoded)
|
|
Drone Library (Geo-Locaation)
|
DJI OC protocol models, Mavlink protocol, Parrot, TBS CrossFire and other brands
|
|
Dynamic Detection Movement Speed
|
≥60km/h (Available for the drones can be decoded)
|
|
Screen Size
|
6.0 Inch
|
|
Battery Capacity
|
12000mAh
|
|
Endurance
|
3～4h
|
|
External Interface
|
Type-C, SMA antenna connector (external screw and internal hole)*2, 3.5mm audio output connector*1, SIM card*1
|
|
Charging Power
|
DC9V, 2A
|
|
Charging Time
|
≤3h（0%-100%）
|
|
Power Consumption
|
≤15W
|
|
Size
|
177mm * 89mm * 29.5mm（±2mm）
|
|
Weight
|
≤580g(±0.05kg，without antenna) ≤46g per antenna
|
|
Operation Temperature
|
-20℃ to +50℃
|
|
Storage Environment
|
15～25℃ RH25～65%
|
|
IP Level
|
IP54
|
Type : Handheld Drone Detection System
Application: Drone Detector
Feature : Wireless Intercom Drone Detector
Place of Origin : Guangdong, China
Brand Name : RF Skypower
Type 1: HZD03-Handheld FPV Detector
Frequency Range : 900MHZ 1.2Ghz 2.4Ghz 5.8Ghz Wifi
Battery life : ≥3hours (single battery)
Drone Models of detection : Including DJI Autel fpv,etc
FREQ RANG 1 : 300-6000MHZ
Frequency Range 2 : 300MHz~6000MHz
Packaging and delivery
Selling Units
Single item
Single package size
13X6X3.5 cm
Single gross weight
0.5 kg
